| Processor Family | Intel® H Series Core 5 Processor (Series 2) – Raptor Lake |
|---|
| Processor | Intel Core™ 5 210H, 8C (4P + 4E) / 12T, P-core 2.2 / 4.8GHz, E-core 1.6 / 3.6GHz, 12MB Intel® Smart Cache |
|---|
| AI PC Category | Non-AI PC |
|---|
| Operating System | Windows® 11 Pro |
|---|
| Graphics | | Graphics | Type | Memory | Key Features |
|---|
| Intel® Graphics | Integrated | Shared | DirectX® 12 |
|
|---|
| Monitor Support | Raptor Lake, Meteor Lake and Arrow Laker: supports up to 4 independent displays (native display and 3 external monitors via HDMI®, USB-C® and Thunderbolt™)
• HDMI® supports up to 4096×2160@60Hz
• USB-C® supports up to 5120×2880@60Hz
• Thunderbolt™ supports up to 7680×4320@60Hz |
|---|
| Chipset | Intel® SoC (System on Chip) platform |
|---|
| Memory | 1x 16GB SODIMM DDR5-5600 |
|---|
| Max Memory | 16 GB, internal memory type: DDR5-SDRAM, memory clock speed: 5600 MHz, memory layout (slots x size): 1 x 16 GB |
|---|
| Memory Slots | Raptor Lake, Meteor Lake and Arrow Lake: two DDR5 SODIMM slots, dual-channel capable |
|---|
| Memory Type | Raptor Lake with H Series processors, Meteor Lake and Arrow Lake: DDR5-5600 |
|---|
| Max Storage Support | up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB |
|---|
| Storage Slot | Raptor Lake, Meteor Lake and Arrow Lake: two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe® 4.0 x4 slot |
|---|
| Storage Type | | Disk Type | Interface | Offering | Security |
|---|
| M.2 2242 SSD | PCIe® NVMe®, PCIe® 4.0 x4 | 256GB | Opal 2.0 |
|
|---|
| Card Reader | No card reader |
|---|
| Audio Chip | High Definition (HD) Audio, Senary SN6147 codec |
|---|
| Speakers | Stereo speakers, 2W x2, Dolby Atmos®, audio by HARMAN |
|---|
| Microphone | Dual-microphone array, 360° far-field, smart noise-cancelling |
|---|
| Camera | 5.0MP, with privacy shutter, fixed focus, temporal noise reduction |
|---|
| Battery | 48Wh Rechargeable Li-ion Battery, supports Rapid Charge Pro (charge up to 50% in 30min) |
|---|
| Battery Life | Local video playback: up to 20.4 hr @150nits |
|---|
| Power Adapter | 65W USB-C® (2-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz |
|---|
| Graphics | Intel Graphics |
|---|
| Max Memory | 64 GB |
|---|
| Storage | 256 GB, storage media: SSD, SSD interface: PCI Express 4.0, SSD form factor: M.2 |
|---|
